Description
- precise and fast laboratory drying oven
- chamber volume 111 litres
- temperature range from 10°C above ambient to 250/300°C
- forced air circulation system in the chamber guarantees homogeneous temperature distribution in all the processes of drying, heating and sterilization of materials in laboratories
- high operation comfort, precise temperature control and short chamber temperature equalization times after the door opening
- higher speed and accuracy of all the tempering procedures ensures economical operation, especially suitable for high humidity materials, for demanding and accurate tests and processes
- wide selection of optional equipment and accessories
- output for connecting a printer or PC
- possibility of validation (IQ, OQ)
Interior of stainless steel material No. 1.4301
| volume |
111 l |
| depth |
370 mm |
| width |
540 mm |
| height |
530 mm |
Tray
| standard equipment |
2 pcs |
| storage area (w × d) |
520 × 335 mm |
| racks |
7 max. number |
| distance between guide rails |
70 mm |
Maximal weight of the load *)
| inside the oven |
50 kg/oven |
| per tray |
20 kg/tray |
External dimensions (including door and handle)
| depth |
640 mm |
| diameter of the air branch outer/inner |
52/49 mm |
| width |
760 mm |
| height (inclusive foots – N) |
860 (N) mm |
Package dimensions (three layers carton)
| depth |
730 mm |
| width |
830 mm |
| depth |
1060 mm |
Working temperature **) (beginning of the regulation) – VENTICELL / VENTICELL plus
| from 10 °C above ambient temp. to |
250 °C |
Temperature accuracy according to DIN 12 880 T2, at working temperature with closed air flap and door, > 50 °C
| time variation cca (±) |
0,4 °C |
| space deviation (±) % cca (±)% of the reached temperature |
1 % |
Time required to reach 250 °C with closed air flap and voltage 230 V
Air exchange speed at 250 °C
Electricity – mains 50/60 Hz
| max. power input |
1,9 kW |
| nominal voltage |
230 V |
| current |
8,3 A |
| stand by |
5 W |
*) Approx. 50 % of the tray area can be filled in a way a uniform air circulation is enabled inside the chamber.Note: All technical data are related to 22 °C of ambient temperature and ±10 % voltage swing rate ventilator 100 %, defrost off, lighting off.
Changes in the design and make reserved.
The values may differ depending on specific charge and media parameters.
